METAL SCREWS

Strength and reliability across a diverse range of roofing, metal to wood, metal to metal, and wood to metal applications. Precision engineered self-drilling points deliver peak driving performance, while premium materials and coatings ensure durability,

Lath Screws Lath Screws
Lath Screws
Roofing Screws Roofing Screws
Roofing Screws
Wood to Metal Screws Wood to Metal Screws
Wood to Metal Screws
Metal to Metal Screws Metal to Metal Screws
Metal to Metal Screws

PROFESSIONAL GRADE METAL SCREWS DELIVER FAST INSTALLATION AND LONG-LASTING FINISH

Nominal Diameter Bit Type Length Thread Diameter Threads Per Inch Head Diameter
#10 5/16" hex Drive 1.5" .21" 16.6 .5"
  • Patented ZXL Fine Finish Head
  • 1 Size
  • No pre-drilling required
  • No red-rust guarantee
  • Penetrates 29 - 20 gayge metal
  • Variety of colors
Nominal Diameter Bit Type Length Thread Diameter Threads Per Inch Head Diameter
#10 1/4" hex Drive 1" - 3" .205" 16.6 .348"
#12 (OSB) 1/4" hex Drive .75" - 1.5" .215" 14 .348"
1/4" (Stitch) 5/16" hex Drive .875" .246" 14 .560"
  • Hex Washer Head
  • Roofing: 7 sizes | Stich: 1 size
  • No pre-drilling required
  • Enhanced corrosion protection
  • Penetrates 29 - 20 gayge metal
  • Variety of colors
Nominal Diameter Bit Type Length Thread Diameter Threads Per Inch Head Diameter
#12 T25 Star Drive 2" - 2.75" .216" 24 .413"
1/4" T30 Star Drive 2" - 23.5" .25" 20 .477"
  • Countersinking Flat Head
  • No pre-drilling required
  • Treated lumber approed
  • Max material thickness
      Metal: 1/4" | Wood: 1-5/8" - 2-1/2"
  • Gray epoxy coating
Nominal Diameter Bit Type Length Thread Diameter Threads Per Inch Head Diameter
#10 T25 Star Drive 1.4375" .19" 24 .45"
  • Wafer Head
  • No pre-drilling required
  • Treated lumber approed
  • Max material thickness
      Metal: 3/16" | Wood: 3/4" - 2-1/2"
  • Gray epoxy coating
Nominal Diameter Bit Type Head Diameter Shank Diameter Thread Diameter Length
#8 T20 Star Drive .5" - 1.625" .178" 20 .44"
  • Low profile head
  • 5 sizes
  • No pre-drilling required
  • Eliminates need for self-drilling and sharp point Lath Screws
  • Penetrates 28 - 18 gauge metal
  • Zinc finish w/ clear sealant
Nominal Diameter Bit Type Length Thread Diameter Threads Per Inch Head Diameter
#8 1/4" Hex Drive
T20 Star Drive		 .5" - 1" .166" 18 .348"
#10 5/16" Hex Drive
T25 Star Drive		 .75" - 1.5" .189" 16 .414"
#12 5/16" Hex Drive
T25 Star Drive		 .75" - 2" .216" 24 .432"
1/4" 3/8" Hex Drive
T30 Star Drive		 .75" - 2.5" .246" 14 .520"
  • Hex Washer Head
  • 13 sizes
  • No pre-drilling required
  • Greater pullout values vs competition
  • Penetrates 26 - 11 gauge metal
  • Zinc finish w/ clear sealant
Nominal Diameter Bit Type Length Thread Diameter Threads Per Inch Head Diameter
#8 T20 Star Drive .5" - .75" .166" 18 .322"
#10 T25 Star Drive .625" - 75" .189" 16 .381"
  • Pan Head
  • 4 sizes
  • No pre-drilling required
  • Greater pullout values vs competition
  • Penetrates 26 - 11 gauge metal
  • Zinc finish w/ clear sealant

Product Specifications

Roofing Screws
Part Number Size Quantity Package Driver Bit Size Material Head Type
117878 #1/4 X 7/8" 250 Project Bag 5/16" Hex Powder Coated - Silver HEX WASHER HEAD W/ NEOPRENE WASHER
117903 #10 X 1" 125 1 Lb Xbox 1/4" Hex Powder Coated - Evergreen HEX WASHER HEAD W/ NEOPRENE WASHER
117904 #10 X 1" 125 1 Lb Xbox 1/4" Hex Powder Coated - Koko Brown HEX WASHER HEAD W/ NEOPRENE WASHER
117905 #10 X 1" 125 1 Lb Xbox 1/4" Hex Powder Coated - Antique Brown HEX WASHER HEAD W/ NEOPRENE WASHER
117906 #10 X 1" 125 1 Lb Xbox 1/4" Hex Powder Coated - Polar White HEX WASHER HEAD W/ NEOPRENE WASHER
117907 #10 X 1" 125 1 Lb Xbox 1/4" Hex Powder Coated - Black HEX WASHER HEAD W/ NEOPRENE WASHER
117908 #10 X 1" 125 1 Lb Xbox 1/4" Hex Powder Coated - Barn Red HEX WASHER HEAD W/ NEOPRENE WASHER
117909 #10 X 1" 125 1 Lb Xbox 1/4" Hex Powder Coated - Forest Green HEX WASHER HEAD W/ NEOPRENE WASHER
117910 #10 X 1" 125 1 Lb Xbox 1/4" Hex Powder Coated - Ivory HEX WASHER HEAD W/ NEOPRENE WASHER
117425 #10 X 1" 250 Project Bag 1/4" Hex Powder Coated - Black HEX WASHER HEAD W/ NEOPRENE WASHER
117434 #10 X 1" 250 Project Bag 1/4" Hex Powder Coated - Antique Brown HEX WASHER HEAD W/ NEOPRENE WASHER
117435 #10 X 1" 250 Project Bag 1/4" Hex Powder Coated - Koko Brown HEX WASHER HEAD W/ NEOPRENE WASHER
117438 #10 X 1" 250 Project Bag 1/4" Hex Powder Coated - Evergreen HEX WASHER HEAD W/ NEOPRENE WASHER
117441 #10 X 1" 250 Project Bag 1/4" Hex Powder Coated - Charcoal Gray HEX WASHER HEAD W/ NEOPRENE WASHER
117450 #10 X 1" 250 Project Bag 1/4" Hex Powder Coated - Barn Red HEX WASHER HEAD W/ NEOPRENE WASHER
117458 #10 X 1" 250 Project Bag 1/4" Hex Powder Coated - Polar White HEX WASHER HEAD W/ NEOPRENE WASHER
117459 #10 X 1" 250 Project Bag 1/4" Hex Powder Coated - Ivory HEX WASHER HEAD W/ NEOPRENE WASHER
117463 #10 X 1" 250 Project Bag 1/4" Hex Powder Coated - Bright White HEX WASHER HEAD W/ NEOPRENE WASHER
117879 #10 X 1" 250 Project Bag 1/4" Hex Powder Coated - Silver HEX WASHER HEAD W/ NEOPRENE WASHER
117900 #10 X 1" 125 1LB Xbox 1/4" Hex Powder Coated - Charcoal Gray HEX WASHER HEAD W/ NEOPRENE WASHER
117901 #10 X 1" 125 1LB Xbox 1/4" Hex Powder Coated - Silver HEX WASHER HEAD W/ NEOPRENE WASHER
117902 #10 X 1" 125 1LB Xbox 1/4" Hex Powder Coated - Bright White HEX WASHER HEAD W/ NEOPRENE WASHER
117961 #10 X 1-1/2" 100 XXL Xbox 1/4" Hex Powder Coated - Bright White HEX WASHER HEAD W/ NEOPRENE WASHER
117912 #10 X 1-1/2" 98 1 Lb Xbox 1/4" Hex Powder Coated - Charcoal Gray HEX WASHER HEAD W/ NEOPRENE WASHER
117913 #10 X 1-1/2" 98 1 Lb Xbox 1/4" Hex Powder Coated - Silver HEX WASHER HEAD W/ NEOPRENE WASHER
117914 #10 X 1-1/2" 98 1 Lb Xbox 1/4" Hex Powder Coated - Bright White HEX WASHER HEAD W/ NEOPRENE WASHER
117915 #10 X 1-1/2" 98 1 Lb Xbox 1/4" Hex Powder Coated - Evergreen HEX WASHER HEAD W/ NEOPRENE WASHER
117916 #10 X 1-1/2" 98 1 Lb Xbox 1/4" Hex Powder Coated - Koko Brown HEX WASHER HEAD W/ NEOPRENE WASHER
117917 #10 X 1-1/2" 98 1 Lb Xbox 1/4" Hex Powder Coated - Antique Brown HEX WASHER HEAD W/ NEOPRENE WASHER
117918 #10 X 1-1/2" 98 1 Lb Xbox 1/4" Hex Powder Coated - Polar White HEX WASHER HEAD W/ NEOPRENE WASHER
117919 #10 X 1-1/2" 98 1 Lb Xbox 1/4" Hex Powder Coated - Black HEX WASHER HEAD W/ NEOPRENE WASHER
117920 #10 X 1-1/2" 98 1 Lb Xbox 1/4" Hex Powder Coated - Barn Red HEX WASHER HEAD W/ NEOPRENE WASHER
117921 #10 X 1-1/2" 98 1 Lb Xbox 1/4" Hex Powder Coated - Forest Green HEX WASHER HEAD W/ NEOPRENE WASHER
117922 #10 X 1-1/2" 98 1 Lb Xbox 1/4" Hex Powder Coated - Ivory HEX WASHER HEAD W/ NEOPRENE WASHER
117500 #10 X 1-1/2" 250 Project Bag 1/4" Hex Powder Coated - Black HEX WASHER HEAD W/ NEOPRENE WASHER
117505 #10 X 1-1/2" 250 Project Bag 1/4" Hex Powder Coated - Antique Brown HEX WASHER HEAD W/ NEOPRENE WASHER
117506 #10 X 1-1/2" 250 Project Bag 1/4" Hex Powder Coated - Koko Brown HEX WASHER HEAD W/ NEOPRENE WASHER
117509 #10 X 1-1/2" 250 Project Bag 1/4" Hex Powder Coated - Evergreen HEX WASHER HEAD W/ NEOPRENE WASHER
117511 #10 X 1-1/2" 250 Project Bag 1/4" Hex Powder Coated - Forest Green HEX WASHER HEAD W/ NEOPRENE WASHER
117512 #10 X 1-1/2" 250 Project Bag 1/4" Hex Powder Coated - Charcoal Gray HEX WASHER HEAD W/ NEOPRENE WASHER
117521 #10 X 1-1/2" 250 Project Bag 1/4" Hex Powder Coated - Barn Red HEX WASHER HEAD W/ NEOPRENE WASHER
117529 #10 X 1-1/2" 250 Project Bag 1/4" Hex Powder Coated - Polar White HEX WASHER HEAD W/ NEOPRENE WASHER
117534 #10 X 1-1/2" 250 Project Bag 1/4" Hex Powder Coated - Bright White HEX WASHER HEAD W/ NEOPRENE WASHER
117880 #10 X 1-1/2" 250 Project Bag 1/4" Hex Powder Coated - Silver HEX WASHER HEAD W/ NEOPRENE WASHER
117465 #10 X 1-1/2" 250 Project Bag 5/16" Hex Powder Coated - Black CUPPED HEX WASHER HEAD W/ NEOPRENE WASHER
117470 #10 X 1-1/2" 250 Project Bag 5/16" Hex Powder Coated - Antique Brown CUPPED HEX WASHER HEAD W/ NEOPRENE WASHER
117471 #10 X 1-1/2" 250 Project Bag 5/16" Hex Powder Coated - Koko Brown CUPPED HEX WASHER HEAD W/ NEOPRENE WASHER
117473 #10 X 1-1/2" 250 Project Bag 5/16" Hex Powder Coated - Evergreen CUPPED HEX WASHER HEAD W/ NEOPRENE WASHER
117476 #10 X 1-1/2" 250 Project Bag 5/16" Hex Powder Coated - Charcoal Gray CUPPED HEX WASHER HEAD W/ NEOPRENE WASHER
117895 #10 X 1-1/2" 250 Project Bag  5/16" Hex Powder Coated - Silver CUPPED HEX WASHER HEAD W/ NEOPRENE WASHER
117935 #10 X 1-1/2" 62 1LB Xbox 5/16" Hex Powder Coated - Charcoal Gray CUPPED HEX WASHER HEAD W/ NEOPRENE WASHER
117936 #10 X 1-1/2" 62 1LB Xbox 5/16" Hex Powder Coated - Silver CUPPED HEX WASHER HEAD W/ NEOPRENE WASHER
117937 #10 X 1-1/2" 62 1LB Xbox 5/16" Hex Powder Coated - Bright White CUPPED HEX WASHER HEAD W/ NEOPRENE WASHER
117938 #10 X 1-1/2" 62 1LB Xbox 5/16" Hex Powder Coated - Evergreen CUPPED HEX WASHER HEAD W/ NEOPRENE WASHER
117939 #10 X 1-1/2" 62 1LB Xbox 5/16" Hex Powder Coated - Koko Brown CUPPED HEX WASHER HEAD W/ NEOPRENE WASHER
117940 #10 X 1-1/2" 62 1LB Xbox 5/16" Hex Powder Coated - Antique Brown CUPPED HEX WASHER HEAD W/ NEOPRENE WASHER
117941 #10 X 1-1/2" 62 1LB Xbox 5/16" Hex Powder Coated - Polar White CUPPED HEX WASHER HEAD W/ NEOPRENE WASHER
117942 #10 X 1-1/2" 62 1LB Xbox 5/16" Hex Powder Coated - Black CUPPED HEX WASHER HEAD W/ NEOPRENE WASHER
117943 #10 X 1-1/2" 62 1LB Xbox 5/16" Hex Powder Coated - Barn Red CUPPED HEX WASHER HEAD W/ NEOPRENE WASHER
117944 #10 X 1-1/2" 62 1LB Xbox 5/16" Hex Powder Coated - Forest Green CUPPED HEX WASHER HEAD W/ NEOPRENE WASHER
117945 #10 X 1-1/2" 62 1LB Xbox 5/16" Hex Powder Coated - Ivory CUPPED HEX WASHER HEAD W/ NEOPRENE WASHER
117958 #10 X 1-1/2" 100 XXL Pack 1/4" Hex Powder Coated - Black HEX WASHER HEAD W/ NEOPRENE WASHER
117959 #10 X 1-1/2" 100 XXL Pack 1/4" Hex Powder Coated - Silver HEX WASHER HEAD W/ NEOPRENE WASHER
117960 #10 X 1-1/2" 100 XXL Pack 1/4" Hex Powder Coated - Tan HEX WASHER HEAD W/ NEOPRENE WASHER
117924 #10 X 2" 77 1 Lb Xbox 1/4" Hex Powder Coated - Charcoal Gray HEX WASHER HEAD W/ NEOPRENE WASHER
117925 #10 X 2" 77 1 Lb Xbox 1/4" Hex Powder Coated - Silver HEX WASHER HEAD W/ NEOPRENE WASHER
117926 #10 X 2" 77 1 Lb Xbox 1/4" Hex Powder Coated - Bright White HEX WASHER HEAD W/ NEOPRENE WASHER
117927 #10 X 2" 77 1 Lb Xbox 1/4" Hex Powder Coated - Evergreen HEX WASHER HEAD W/ NEOPRENE WASHER
117928 #10 X 2" 77 1 Lb Xbox 1/4" Hex Powder Coated - Koko Brown HEX WASHER HEAD W/ NEOPRENE WASHER
117929 #10 X 2" 77 1 Lb Xbox 1/4" Hex Powder Coated - Antique Brown HEX WASHER HEAD W/ NEOPRENE WASHER
117930 #10 X 2" 77 1 Lb Xbox 1/4" Hex Powder Coated - Polar White HEX WASHER HEAD W/ NEOPRENE WASHER
117931 #10 X 2" 77 1 Lb Xbox 1/4" Hex Powder Coated - Black HEX WASHER HEAD W/ NEOPRENE WASHER
117932 #10 X 2" 77 1 Lb Xbox 1/4" Hex Powder Coated - Barn Red HEX WASHER HEAD W/ NEOPRENE WASHER
117933 #10 X 2" 77 1 Lb Xbox 1/4" Hex Powder Coated - Forest Green HEX WASHER HEAD W/ NEOPRENE WASHER
117934 #10 X 2" 77 1 Lb Xbox 1/4" Hex Powder Coated - Ivory HEX WASHER HEAD W/ NEOPRENE WASHER
117566 #10 X 2" 250 Project Bag 1/4" Hex Powder Coated - Black HEX WASHER HEAD W/ NEOPRENE WASHER
117571 #10 X 2" 250 Project Bag 1/4" Hex Powder Coated - Antique Brown HEX WASHER HEAD W/ NEOPRENE WASHER
117572 #10 X 2" 250 Project Bag 1/4" Hex Powder Coated - Koko Brown HEX WASHER HEAD W/ NEOPRENE WASHER
117574 #10 X 2" 250 Project Bag 1/4" Hex Powder Coated - Evergreen HEX WASHER HEAD W/ NEOPRENE WASHER
117577 #10 X 2" 250 Project Bag 1/4" Hex Powder Coated - Charcoal Gray HEX WASHER HEAD W/ NEOPRENE WASHER
117586 #10 X 2" 250 Project Bag 1/4" Hex Powder Coated - Barn Red HEX WASHER HEAD W/ NEOPRENE WASHER
117594 #10 X 2" 250 Project Bag 1/4" Hex Powder Coated - Polar White HEX WASHER HEAD W/ NEOPRENE WASHER
117599 #10 X 2" 250 Project Bag 1/4" Hex Powder Coated - Bright White HEX WASHER HEAD W/ NEOPRENE WASHER
117881 #10 X 2" 250 Project Bag 1/4" Hex Powder Coated - Silver HEX WASHER HEAD W/ NEOPRENE WASHER
117882 #10 X 2-1/2" 250 Project Bag 1/4" Hex Powder Coated - Silver HEX WASHER HEAD W/ NEOPRENE WASHER
117883 #10 X 3" 250 Project Bag 1/4" Hex Powder Coated - Silver HEX WASHER HEAD W/ NEOPRENE WASHER
117956 #12 X 1-1/2" 20 Xl Pack 1/4" Hex Powder Coated - Silver HEX WASHER HEAD W/ NEOPRENE WASHER
117957 #12 X 1-1/2" 20 Xl Pack 1/4" Hex Powder Coated - Bright White HEX WASHER HEAD W/ NEOPRENE WASHER
117948 #12 X 1-1/2" 89 1Lb Xbox 1/4" Hex Powder Coated - Silver HEX WASHER HEAD W/ NEOPRENE WASHER
117949 #12 X 1-1/2" 89 1Lb Xbox 1/4" Hex Powder Coated - Bright White HEX WASHER HEAD W/ NEOPRENE WASHER
117954 #12 X 3/4" 35 Xl Pack 1/4" Hex Powder Coated - Silver HEX WASHER HEAD W/ NEOPRENE WASHER
117955 #12 X 3/4" 35 Xl Pack 1/4" Hex Powder Coated - Bright White HEX WASHER HEAD W/ NEOPRENE WASHER
117946 #12 X 3/4" 141 1Lb Xbox 1/4" Hex Powder Coated - Silver HEX WASHER HEAD W/ NEOPRENE WASHER
117947 #12 X 3/4" 141 1Lb Xbox 1/4" Hex Powder Coated - Bright White HEX WASHER HEAD W/ NEOPRENE WASHER
Wood to Metal Screws
Part Number Size Quantity Driver Bit Size Material Head Type
116150 #10-24 X 1-7/16" 68 T25 Epoxy Coated - Gray Star Drive
116148 #12-24 X 2" 42 T25 Epoxy Coated - Gray Star Drive
116169 #12-24 X 2-1/2" 35 T25 Epoxy Coated - Gray Star Drive
116149 #12-24 X 2-3/4" 30 T25 Epoxy Coated - Gray Star Drive
116180 #12-24 X 2-3/4" 150 T25 Epoxy Coated - Gray Star Drive
116181 #12-24 X 2-3/4" 360 T25 Epoxy Coated - Gray Star Drive
116170 #1/4 - 20 X 2" 35 T25 Epoxy Coated - Gray Star Drive
116171 #1/4 - 20 X 2" 175 T25 Epoxy Coated - Gray Star Drive
116172 #1/4 - 20 X 2-3/4" 30 T25 Epoxy Coated - Gray Star Drive
116173 #1/4 - 20 X 2-3/4" 150 T25 Epoxy Coated - Gray Star Drive
116174 #1/4 - 20 X 2-3/4" 360 T25 Epoxy Coated - Gray Star Drive
116175 #1/4 - 20 X 3" 28 T25 Epoxy Coated - Gray Star Drive
116176 #1/4 - 20 X 3" 140 T25 Epoxy Coated - Gray Star Drive
116177 #1/4 - 20 X 3-1/2" 336 T25 Epoxy Coated - Gray Star Drive
116178 #1/4 - 20 X 3-1/2" 25 T25 Epoxy Coated - Gray Star Drive
116179 #1/4 - 20 X 3-1/2" 125 T25 Epoxy Coated - Gray Star Drive
Lath Screws
Part Number Size Quantity Package Driver Bit Size Material Head Type
42645 #8 X 1-3/4" 50 XL Pack T20 Dichromate - Yellow Truss
48324C #8 X 1-3/4" 150 Small Jar T20 Dichromate - Yellow Truss
48647 #8 X 1-3/4" 147 1LB Chipboard T20 Dichromate - Yellow Truss
48325C #8 X 2-1/2" 107 1LB Chipboard T20 Dichromate - Yellow Truss
48648 #8 X 2-1/2" 107 1LB Chipboard T20 Dichromate - Yellow Truss
42646 #8 X 2-1/2" 50 XL Pack T20 Dichromate - Yellow Truss
Metal to Metal Screws
Part Number Size Quantity Package Driver Bit Size Material Head Type
116115 #8 X 1/2" 225 T20 Zinc Plated – Silver XXL Xbox Pan
116116 #8 X 3/4" 180 T20 Zinc Plated – Silver XXL Xbox Pan
116117 #10 X 5/8" 142 T20 Zinc Plated – Silver XXL Xbox Pan
116118 #10 X 3/4" 127 T20 Zinc Plated – Silver XXL Xbox Pan
116119 #8 X 1/2" 210 T20 Zinc Plated – Silver XXL Xbox Hex Washer Head
116120 #8 X 3/4" 135 T20 Zinc Plated – Silver XXL Xbox Hex Washer Head
116122 #10 X 3/4" 112 T25 Zinc Plated – Silver XXL Xbox Hex Washer Head
116121 #8 X 1" 127 T20 Zinc Plated – Silver 1 Lb Xbox Hex Washer Head
116123 #10 X 1" 105 T25 Zinc Plated – Silver 1 Lb Xbox Hex Washer Head
116124 #10 X 1-1/2" 68 T25 Zinc Plated – Silver 1 Lb Xbox Hex Washer Head
116125 #12 X 3/4" 90 T25 Zinc Plated – Silver 1 Lb Xbox Hex Washer Head
116126 #12 X 1" 75 T25 Zinc Plated – Silver 1 Lb Xbox Hex Washer Head
116127 #12 X 1-1/2" 60 T25 Zinc Plated – Silver 1 Lb Xbox Hex Washer Head
116128 #12 X 2" 45 T25 Zinc Plated – Silver 1 Lb Xbox Hex Washer Head
116129 #1/4 X 1-1/2" 37 T30 Zinc Plated – Silver 1 Lb Xbox Hex Washer Head
116130 #1/4 X 2-1/2" 22 T30 Zinc Plated – Silver 1 Lb Xbox Hex Washer Head
116131 #1/4 X 3/4" 52 T30 Zinc Plated – Silver 1 Lb Xbox Hex Washer Head
116148 #12 X 2" 42 T25 Epoxy Coated - Gray 1Lb Xbox Flat
116149 #12 X 2-3/4" 30 T25 Epoxy Coated - Gray 1Lb Xbox Flat
116150 #10 X 1-7/16" 68 T25 Epoxy Coated - Gray 1Lb Xbox Wafer
116132 #8 X 1/2" 180 T20 Zinc Plated – Silver XXL XBOX Truss Washer
116133 #8 X 3/4" 140 T20 Zinc Plated – Silver XXL XBOX Truss Washer
116134 #8 X 1" 100 T20 Zinc Plated – Silver XXL XBOX Truss Washer
116135 #8 X 1/-1/4" 80 T20 Zinc Plated – Silver XXL XBOX Truss Washer
116136 #8 X 1-5/8" 60 T20 Zinc Plated – Silver XXL XBOX Truss Washer
